Pneumatic diaphragm pump is a new type of conveying machinery, is a new type of pump in China. Using compressed air as power source, for all kinds of corrosive liquid, liquid with particles, high viscosity, volatile, flammable, highly toxic liquid, can be pumped out. Pneumatic diaphragm pump has four materials: plastic, aluminum alloy, cast iron, stainless steel. Diaphragm pump according to different liquid media are made of butadiene rubber, neoprene rubber, fluorine rubber, PTFE, polytetrafluoroethylene. To meet the needs of different users. Placed in a variety of special occasions, used to pump a kind of conventional pump can not be pumped medium, have achieved satisfactory results.
For modern people, see things more like environmental protection, intelligent products, pneumatic diaphragm pump just meet these requirements:
Environmental protection: pneumatic diaphragm pump itself has a self-priming function, does not consume too much electricity, no lubrication so easy maintenance, not due to drip pollution of the working environment.
Safety: pneumatic diaphragm pump can run empty, without danger, is a guarantee for personal safety.
Intelligent: No complex control system, no cable, fuse and other pneumatic diaphragm pump small size, light weight, easy to move.
Function: Pneumatic diaphragm pump for all kinds of corrosive liquid, liquid with particles, high viscosity, volatile, flammable, highly toxic liquid, can be pumped out.
Pneumatic diaphragm pump also has many advantages
1, due to the use of air for power, so the flow with the change of back pressure and automatic adjustment, suitable for high viscosity fluid. And the working point of the centrifugal pump is set on the basis of water. If it is used for the fluid with slightly higher viscosity, it needs to support the reducer or frequency conversion governor. The cost is greatly increased, and the same is true for the gear pump.
2, in flammable and explosive environment with pneumatic pump reliable and low cost, such as fuel, gunpowder, explosive delivery, because:, ground after the impossible spark; Second, no heat generation in the work, the machine will not overheat; Third, the fluid will not overheat because the diaphragm pump on the fluid agitation is small.
3. In addition, the diaphragm pump is small and easy to move, does not need foundation, occupies very little ground, and is simple and economical to install. Can be used as mobile material transfer pump.
4, in the site of bad places, such as construction sites, industrial and mining waste water discharge, due to the impurities in the sewage and complex composition, pipeline is easy to plug, so that the electric pump will form too high load, motor heating vulnerable. Pneumatic diaphragm pump can pass through the particles and flow adjustable, pipe blocking automatically stop to unobstructed.
5, or some tests to ensure that there is no impurity pollution of raw materials.
6, can be used to transport chemical properties of relatively unstable fluid, such as: photosensitive materials, flocculant, etc. This is because the diaphragm pump has low shear force and little physical impact on the material.
7, in hazardous, corrosive material processing, diaphragm pump can be completely separated from the material and the outside world.
